Racor 3120R-RAC-32 Fuel Filter Water Separator

SKU:
RAC3120R-RAC-32
|
MPN
3120R-RAC-32
|
UPC:
706672014795
$198.99 - $1,134.29
Current Stock:
Adding to cart… The item has been added
Racor 3120R-RAC-32 Fuel Filter Water Separator.

The new 3120R-RAC-32 will handle flows up to 120 GPH and is the optimum choice for high performance marine inboard or outboard gasoline engines.

Features:
  • Removes 99 percent of free water and sediment

  • Includes 10 micron Aquabloc®II element - S3232TUL

  • 2-port, with 1/2”-14 NPTF threads

  • Filters gasoline fuel

  • UL listed metal bowl

  • White powder coated to prevent corrosion


    • The lower the micron rating, the finer the filtration. Follow your engine manufacturer's recommendation for fuel filter micron rating.

  • S = Secondary/Final 2 micron (Brown)

  • T = Primary or Secondary/Final 10 micron (Blue)

  • P = Primary 30 micron (Red)
    • Brand Parker | Racor Division
    Cross Reference / Specs

  • Application: Outboard, Inboard
  • Maximum Flow Rate: 120 GPH (454 LPH)
  • Replacement Filter: 10 micron = S3232TUL
  • Center threads: 1"-14
  • Port Size: 1/2"-14 NPTF
  • Number of Ports: Inlets = 1, Outlets = 1
  • Height: 10.4 in. (26.4 cm)
  • Width: 4.0 in. (10.2 cm)
  • Depth: 5.0 in. (12.7 cm)
  • Weight (dry): 2.0 lb (0.90 kg)
  • Clean Pressure Drop: 0.15 PSI
  • Maximum Allowable Pressure: 7 PSI (0.5 bar)
  • Underbowl Clearance: 1.0 in. (2.5 cm)
  • Water Removal Efficiency: 99 percent
  • Operating Temperature: -40° to +255°F (-40° to +124°C)
  • Use on vacuum side of fuel or transfer pump
    		•
